Cluster Hammer
Large-diameter foundation drilling
A cluster-hammer family shown in the foundation catalog. Discuss the required pile diameter, rock formation, rig and available air supply before selecting an assembly.
- Model / family
- Cluster
- Cuttings discharge
- Forward / reverse
Technical data is listed below. The complete catalog is available when discussing your requirements.
Inquire about this product ↗PRODUCT DATA
Request the complete catalog ↗Technical specifications
Extracted from the supplier catalog · PDF page 18
| Cuttings discharge | Forward / reverse |
|---|
Cluster hammer variants
| Model | Hole diameter (mm) | Sub-hammers | Air consumption (m³/min) |
|---|---|---|---|
| HZ-600 | 600 | 4 | 60 |
| HZ-800 | 800 | 7 | 90 |
| HZ-1000 | 1000 | 7 | 120 |
| HZ-1200 | 1200 | 9 | 180 |
| HZ-1500 | 1500 | 12 | 210 |
The catalog prints rotary speed as “10rap/min” and working pressure as “≥16kg”. These non-standard entries are not converted or presented as confirmed operating values; obtain confirmed units and conditions from the supplier.
Catalog data is for selection reference. Confirm current specifications, connection, air supply and ground conditions with the supplier before ordering.
